System Overview
Advantages
- The slope of the support and the rounded design of the Protègenet facilitates the evacuation of water.
- The tip can be used to prevent slippage and lateral run-off.
- The purpose of the fallout is to ensure aesthetic closure, as well as protection against sharp edges, particularly on the ground floor.
Elements of the system
A - Window support with its rounded edge
B - Extruded aluminum end cap
Finish
- Crude Alu
- Natural anodised aluminum
- Aluminum lacquered RAL colors
Description of the PR 3 system (with rear reading)
The window support
The PR3 model provides optimal protection against seepage through the rear section.
Additional protection by means of a continuous sealing cord at the back is essential.
The tips
The tips are made from an extruded aluminum profile, for more security.
In addition, the grooves, integrated into the profile, provide an additional barrier to infiltration.
Advantages :
- Looks good aesthetically
- Avoids lateral sagging
- Protects from sharp angles
- Allows good protection thanks to its reading in the back part.
Where insulated panels are used, dani alu offers the no. 3 ITE nozzle.
This is implemented by engraving the panel insulation.
This is implemented by engraving the panel insulation.
Example of use
Description of the PR 2 system (without reading in the rear part)
The window support
Basic solution without impacting carpentry.
Additional protection by a continuous sealing cord at the back is essential.
The tips
The tips are made from an extruded aluminum profile, for better holding.
In addition, the grooves, integrated into the profile, provide an additional barrier to infiltration.
Advantages :
- Looks good aesthetically
- Avoids lateral sagging
- Protects from sharp angles
Where insulated panels are used, dani alu offers the no. 2 ITE nozzle.
This is implemented by engraving the panel insulation.
This is implemented by engraving the panel insulation.
Example of use
The PR2 is the simplest and most cost-effective solution, without any impact to the carpentry.
Special parts
Our design department can advise you on the production of the following special parts:
- Outgoing angle
- Incoming Angle
- Pillar contour
- Connecting piece for spinning or splitting elements
Implementation
- Protègenet is simply glued in place
- First, the lateral ends
- Then, the lengths
- This is solidified by a continuous line of sealant at the back of the support
